Preis von

$ 18,570

Leistung

18.22 hp/8500

Max. Drehmoment

17.2N·m/6500 r/min

Trockengewicht

136

Technische Daten

  • Displacement (cc)

    175

    Type

    1-cylinder/4-stroke/4-valve

    Bore x Stroke (mm)

    61×59.6

    Power/rpm

    18.22 hp/8500

    Max. torque

    17.2N·m/6500 r/min

    Compression ratio

    11.5:1

    Fuel system

    Bosch EFI

    Valve train

    SOHC

    Ignition

    TCI

    Starter

    Electric

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Lateral-mounted-liquid-cooled

  • Gearbox

    Automatic CVT

    Transmission type

    V-Belt

    Clutch type

    Automatic

  • Front wheel

    Alloy

    Front suspension

    Telescopic forks

    Front suspension travel (mm)

    93

    Front tyre

    CST 110/70-14

    Rear wheel

    Alloy

    Rear suspension

    Dual shock-absorber

    Rear suspension travel (mm)

    106

    Rear tyre

    CST 130/70-13

    Front brake

    Disc, 4-piston caliper

    Front brakes diameter (mm)

    260

    Rear brake

    Disc, 1-piston caliper

    Rear brakes diameter (mm)

    220

  • Curb weight (kg)

    136

    Seat height (mm)

    770

    Overall length (mm)

    1970

    Overall width (mm)

    770

    Overall height (mm)

    1150

    Ground clearance (mm)

    150

    Wheelbase (mm)

    1315

    Fuel capacity (L)

    8

    Top speed (km/h)

    110

    Max. load (kg)

    150

    Battery

    12V8Ah

  • Ride Modes selection

    -

    Throttle configuration

    Dual cable throttle control

  • Dashboard Type

    TFT, 6 inch Dashboard

    Gear Indicator

    -

    USB Charging port

    Type-A + Type-C

    Handle switch with illumination

    -

    Windshield

    -

  • Headlight

    Daytime Running Light (DRL) + Led projector lenses for optimal visibility

    Turn signal

    LED

    Taillight

    LED

    Hazard light

    Included

    Automatic lighting system

    Included

  • ABS system

    Dual-Channel

    ABS off function

    -

    ABS Pro, Cornering anti-lock braking system

    -

    Tyre pressure monitoring system (TPMS)

    Included

    Traction control system (TCS)

    Included
