Prezzo di Listino

N/A

Potenza

20.5kW/8750

Coppia

25.0N·m/7000 r/min

Peso a secco (kg)

151

Specifiche tecniche

  • Displacement (cc)

    292

    Type

    1-cylinder/4-stroke/4-valve

    Bore x Stroke (mm)

    78×61.2

    Power/rpm

    20.5kW/8750

    Max. torque

    25.0N·m/7000 r/min

    Compression ratio

    11.1:1

    Fuel system

    EFI

    Valve train

    DOHC

    Ignition

    TCI

    Starter

    Electric

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Liquid-cooled

  • Gearbox

    6-speed

    Transmission type

    Chain

    Clutch type

    Sliding clutch

  • Front wheel

    Alloy

    Front suspension

    Upside-down telescopic forks

    Front suspension travel (mm)

    125

    Front tyre

    110/70R17 M/C

    Rear wheel

    Alloy

    Rear suspension

    Mono-shock-absorber

    Rear suspension travel (mm)

    46

    Rear tyre

    140/60R17 M/C

    Front brake

    Disc

    Front brakes diameter (mm)

    292

    Rear brake

    Disc

    Rear brakes diameter (mm)

    220

  • Curb weight (kg)

    151

    Seat height (mm)

    795

    Overall length (mm)

    1990

    Overall width (mm)

    780

    Overall height (mm)

    1070

    Ground clearance (mm)

    150

    Wheelbase (mm)

    1360

    Fuel capacity (L)

    12.5

    Top speed (km/h)

    139

    Max. load (kg)

    150

    Battery

    12V9Ah
