Price From

N/A

Power

18.5 CV / 8500

Max. Torque

17.2N·m/6500 r/min

Curb Weight (KG)

137

Tech Specs

  • Displacement (cc)

    174

    Bore x Stroke (mm)

    61×59.6

    Power/rpm

    18.5 CV / 8500

    Max. torque

    17.2N·m/6500 r/min

    Compression ratio

    11.5:1

    Fuel system

    EFI

    Valve train

    SOHC

    Ignition

    TCI

    Starter

    Electric

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Lateral-mounted-liquid-cooled

  • Gearbox

    Automatic CVT

    Transmission type

    V-Belt

    Clutch type

    Automatic

  • Front wheel

    Alloy

    Front suspension

    Telescopic forks

    Front suspension travel (mm)

    75

    Front tyre

    100/80-14

    Rear wheel

    Alloy

    Rear suspension

    Dual shock-absorber, continuously adjustable preload

    Rear suspension travel (mm)

    65

    Rear tyre

    120/70-14

    Front brake

    Disc, 2-piston caliper

    Front brakes diameter (mm)

    230

    Rear brake

    Disc, 2-piston caliper

    Rear brakes diameter (mm)

    218

  • Curb weight (kg)

    137

    Seat height (mm)

    790

    Overall length (mm)

    1970

    Overall width (mm)

    730

    Overall height (mm)

    1175

    Ground clearance (mm)

    135

    Wheelbase (mm)

    1370

    Fuel capacity (L)

    11

    Top speed (km/h)

    115

    Max. load (kg)

    160

    Battery

    12V8.6Ah

  • Dashboard Type

    LCD

    USB Charging port

    Type-A + Type-C

  • Headlight

    Daytime Running Light (DRL) + Dual Led projector lenses for optimal visibility

    Turn signal

    LED

    Taillight

    LED

    Hazard light

    Included

  • ABS system

    Dual-Channel
