Prix à partir de

N/A

Puissance

13kW/8000

Couple Max.

16.5N·m/6000 r/min

Poids à sec

166

Spécifications techniques

  • Displacement (cc)

    249

    Type

    2-cylinder/4-stroke/4-valve

    Bore x Stroke (mm)

    55×52.4

    Power/rpm

    13kW/8000

    Max. torque

    16.5N·m/6000 r/min

    Compression ratio

    9:1

    Fuel system

    EFI

    Valve train

    SOHC

    Ignition

    TCI

    Starter

    Electric

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Air-cooled

  • Gearbox

    5-speed

    Transmission type

    Chain

    Clutch type

    Wet multi-plate

  • Front wheel

    Alloy

    Front suspension

    Telescopic forks

    Front suspension travel (mm)

    120

    Front tyre

    90/90-18

    Rear wheel

    Alloy

    Rear suspension

    Dual shock-absorber

    Rear suspension travel (mm)

    70

    Rear tyre

    130/90-15

    Front brake

    Disc

    Front brakes diameter (mm)

    260

    Rear brake

    Disc / Drum

    Rear brakes diameter (mm)

    130 / 240

  • Curb weight (kg)

    166

    Seat height (mm)

    710

    Overall length (mm)

    2200

    Overall width (mm)

    850

    Overall height (mm)

    1130

    Ground clearance (mm)

    140

    Wheelbase (mm)

    1460

    Fuel capacity (L)

    14

    Top speed (km/h)

    114

    Max. load (kg)

    173

    Battery

    12V9Ah
