ราคาเริ่มต้นที่

N/A

พลัง

13.5kW/8500

แม็กซ์แรงบิด

16.0N·m/7500 r/min

น้ำหนักแห้ง

179

ข้อมูลจำเพาะทางเทคนิค

  • ขนาดเครื่องยนต์ (ซี.ซี.) | Engine Displacement

    248.9

    ประเภทเครื่องยนต์ | Engine Type

    2 สูบ 4 จังหวะ 4 วาล์ว | 2 Cylinders, 4 Stroke, 4 Valves

    ช่วงชัก x กระบอกสูบ (มม.) | Bore x Stroke

    49x66

    พลังกำลัง | Max Power/rpm

    13.5kW/8500

    แรงบิดสูงสุด | Max. torque

    16.0N·m/7500 r/min

    อัตราส่วนกำลังอัด | Compression Ratio

    10:1

    ระบบจ่ายน้ำมันเชื้อเพลิง | Fuel Injection System

    EFI

    ระบบวาล์ว | Valve train

    SOHC

    การจุดระเบิด | Ignition

    TCI

    ระบบสตาร์ท | Starter

    สตาร์ทอัตโนมัติ | Electric

    ระบบหล่อลื่น | Lubrication system

    Pressure splash lubrication

    ระบบระบายความร้อน | Cooling system

    Air-cooled

  • เกียร์ | Gearbox

    5-speed

    อัตราทดเฟืองท้าย | Final drive

    V-Belt

    รูปแบบครัทช์ | Clutch type

    Wet multi-plate

  • ล้อหน้า | Front wheel

    Alloy

    ระบบกันสะเทือนหน้า | Front suspension

    Upside-down telescopic forks

    ขนาดระบบกันสะเทือนหน้า | Front suspension travel (mm)

    110

    ขนาดยางหน้า | Front tyre

    120/80-16

    ล้อหลัง | Rear wheel

    Alloy

    ระบบกันสะเทือนหลัง | Rear suspension

    Dual shock-absorber

    ขนาดระบบกันสะเทือนหลัง | Rear suspension travel (mm)

    50

    ขนาดยางหลัง | Rear tyre

    140/70-16

    เบรคหน้า | Front brakes

    Disc

    ขนาดดิสก์เบรกหน้า | Front brakes diameter (mm)

    280

    เบรคหลัง | Rear brakes

    Disc

    ขนาดดิสก์เบรกหลัง | Rear brakes diameter (mm)

    240

  • น้ำหนักตัวรถ | Dry weight (kg)

    179

    ความสูงสุทธิ | Overall height (mm)

    1090

    ความสูงจากพื้น | Ground clearance (mm)

    160

    ระยะฐานล้อ | Wheelbase (mm)

    1530

    ความจุถังน้ำมัน | Fuel capacity (L)

    20

    ความเร็วสูงสุด | Top speed (km/h)

    110

    น้ำหนักสุทธิ | Max. load (kg)

    150

    แบตเตอรี่ | Battery

    12V8Ah

  • ความสูงจากเบาะ | Seat height (mm)

    715

    ความยาวสุทธิ | Overall length (mm)

    2230

    ความกว้างทั้งหมด | Overall width (mm)

    920
