Price From

N/A

Power

8.16 hp/7500

Max. Torque

8.2N·m/6000 r/min

Curb Weight (KG)

105

Tech Specs

  • Displacement (cc)

    124.6

    Type

    1-cylinder/4-stroke/2-valve

    Bore x Stroke (mm)

    52.4x57.8

    Power/rpm

    8.16 hp/7500

    Max. torque

    8.2N·m/6000 r/min

    Compression ratio

    9.2:1

    Fuel system

    Carburetor

    Valve train

    SOHC

    Ignition

    CDI

    Starter

    Electric & Kick

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Forced-air-cooled

  • Gearbox

    Automatic CVT

    Transmission type

    V-Belt

    Clutch type

    Automatic

  • Front wheel

    Alloy

    Front suspension

    Telescopic forks

    Front suspension travel (mm)

    82

    Front tyre

    Kenda 3.50-10

    Rear wheel

    Alloy

    Rear suspension

    Dual shock-absorber

    Rear suspension travel (mm)

    55

    Rear tyre

    Kenda 3.50-10

    Front brake

    Disc, 2-piston caliper

    Front brakes diameter (mm)

    180

    Rear brake

    Drum

    Rear brakes diameter (mm)

    110

  • Curb weight (kg)

    105

    Seat height (mm)

    750

    Overall length (mm)

    1860

    Overall width (mm)

    695

    Overall height (mm)

    1115

    Ground clearance (mm)

    110

    Wheelbase (mm)

    1300

    Fuel capacity (L)

    6.6

    Top speed (km/h)

    90

    Max. load (kg)

    150

    Battery

    12V6Ah

  • Throttle configuration

    Single cable throttle control

  • Dashboard Type

    LCD

    USB Charging port

    Included

  • Headlight

    Incandescent lamp

    Turn signal

    Front: LED; Rear: Incandescent lamp

    Taillight

    Incandescent lamp
