Price From

N/A

Power

2.9 CV / 7500

Max. Torque

3.1 N·m / 6500 rpm

Curb Weight (KG)

102

Tech Specs

  • Displacement (cc)

    49.6

    Type

    1-cylinder/4-stroke/2-valve

    Bore x Stroke (mm)

    39×41.5

    Power/rpm

    2.9 CV / 7500

    Max. torque

    3.1 N·m / 6500 rpm

    Compression ratio

    10.5:1

    Fuel system

    Carburetor

    Valve train

    SOHC

    Ignition

    CDI

    Starter

    Electric & Kick

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Forced-air-cooled

  • Gearbox

    Automatic CVT

    Transmission type

    V-Belt

    Clutch type

    Automatic

  • Front wheel

    Alloy

    Front suspension

    Telescopic forks

    Front suspension travel (mm)

    68

    Front tyre

    90/90-12

    Rear wheel

    Alloy

    Rear suspension

    Dual shock-absorber, 5-stage adjustable preload

    Rear suspension travel (mm)

    56

    Rear tyre

    90/90-12

    Front brake

    Disc, 2-piston caliper

    Front brakes diameter (mm)

    190

    Rear brake

    Drum

    Rear brakes diameter (mm)

    110

  • Curb weight (kg)

    102

    Seat height (mm)

    775

    Overall length (mm)

    1850

    Overall width (mm)

    665

    Overall height (mm)

    1128

    Ground clearance (mm)

    110

    Wheelbase (mm)

    1305

    Fuel capacity (L)

    5.5

    Top speed (km/h)

    50

    Max. load (kg)

    150

    Battery

    12V6Ah

  • Dashboard Type

    LCD

    USB Charging port

    Type-A

  • Headlight

    Daytime Running Light (DRL) + Dual Led projector lenses for optimal visibility

    Turn signal

    LED

    Taillight

    LED

    Hazard light

    Included
