Price From

N/A

Power

6.2kW at 7500 r/min

Max. Torque

9.0N·m/6000 r/min

Dry Weight (KG)

99

Tech Specs

  • Displacement (cc)

    117

    Type

    1-cylinder/4-stroke/2-valve

    Bore x Stroke (mm)

    52.4x54.4

    Power

    6.2kW at 7500 r/min

    Max. torque

    9.0N·m/6000 r/min

    Compression ratio

    9.5:1

    Fuel system

    EFI

    Valve train

    SOHC

    Ignition

    TCI

    Starter

    Electric

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Forced-air-cooled

  • Gearbox

    Automatic CVT

    Transmission type

    V-Belt

    Clutch type

    Automatic

  • Front wheel

    Alloy

    Front suspension

    Telescopic forks

    Front suspension travel (mm)

    95

    Front tyre

    CST 100/90-12

    Rear wheel

    Alloy

    Rear suspension

    Mono-shock-absorber, adjustable

    Rear suspension travel (mm)

    65

    Rear tyre

    CST 110/90-12

    Front brake

    Disc, 1-piston caliper with CBS

    Front brakes diameter (mm)

    190

    Rear brake

    Drum

    Rear brakes diameter (mm)

    130

  • Curb weight (kg)

    99

    Seat height (mm)

    750

    Overall length (mm)

    1840

    Overall width (mm)

    685

    Overall height (mm)

    1165

    Ground clearance (mm)

    135

    Wheelbase (mm)

    1270

    Fuel capacity (L)

    4

    Top speed (km/h)

    90

    Max. load (kg)

    150

    Battery

    12V6.5Ah
