Price From

N/A

Power

9.6kW at 8000 r/min

Max. Torque

13.0N·m/6000 r/min

Dry Weight (KG)

122

Tech Specs

  • Displacement (cc)

    200

    Type

    1-cylinder/4-stroke/2-valve

    Bore x Stroke (mm)

    ø63.5×63

    Power

    9.6kW at 8000 r/min

    Max. torque

    13.0N·m/6000 r/min

    Compression ratio

    8.6:1

    Fuel system

    Carburetor

    Valve train

    OHV

    Ignition

    CDI

    Starter

    Electric & Kick

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Air-cooled

  • Gearbox

    5-speed

    Transmission type

    Chain

    Clutch type

    Wet multi-plate

  • Front wheel

    Alloy

    Front suspension

    Telescopic forks

    Front tyre

    80/90-17

    Rear wheel

    Alloy

    Rear suspension

    Dual shock-absorber

    Rear tyre

    120/80-17

    Front brake

    Disc

    Rear brake

    Drum

  • Curb weight (kg)

    122

    Seat height (mm)

    765

    Overall length (mm)

    2025

    Overall width (mm)

    775

    Overall height (mm)

    1095

    Ground clearance (mm)

    170

    Wheelbase (mm)

    1265

    Fuel capacity (L)

    14

    Top speed (km/h)

    105

    Max. load (kg)

    150

    Battery

    12V7.4Ah
