Prezzo di Listino

N/A

Potenza

14.0kW/6500

Coppia

22.0N·m/6000 r/min

Peso a secco (kg)

154

Specifiche tecniche

  • Displacement (cc)

    278.2

    Type

    1-cylinder/4-stroke/4-valve

    Bore x Stroke (mm)

    75×63

    Power/rpm

    14.0kW/6500

    Max. torque

    22.0N·m/6000 r/min

    Compression ratio

    11:1

    Fuel system

    EFI

    Valve train

    SOHC

    Ignition

    TCI

    Starter

    Electric

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Liquid-cooled

  • Gearbox

    Automatic CVT

    Transmission type

    V-Belt

    Clutch type

    Automatic

  • Front wheel

    Alloy

    Front suspension

    KYB telescopic forks

    Front suspension travel (mm)

    50

    Front tyre

    Timsun 120/70-12

    Rear wheel

    Alloy

    Rear suspension

    Dual shock-absorber KYB, 5-stage adjustable preload

    Rear suspension travel (mm)

    50

    Rear tyre

    Timsun 120/70-12

    Front brake

    Disc, caliper Nissin with Bosch ABS

    Front brakes diameter (mm)

    230

    Rear brake

    Disc, caliper Nissin with Bosch ABS

    Rear brakes diameter (mm)

    220

  • Curb weight (kg)

    154

    Seat height (mm)

    780

    Overall length (mm)

    1985

    Overall width (mm)

    720

    Overall height (mm)

    1170

    Ground clearance (mm)

    140

    Wheelbase (mm)

    1390

    Fuel capacity (L)

    10

    Top speed (km/h)

    120

    Max. load (kg)

    150

    Battery

    12V10Ah
