Precio desde

N/A

Potencia

22.0kW/8500

Máximo. Torsión

26.5N·m/6500 r/min

Peso seco

175

Especificaciones técnicas

  • Displacement (cc)

    298

    Type

    2-cylinder/4-stroke/8-valve

    Bore x Stroke (mm)

    58×56.4

    Power/rpm

    22.0kW/8500

    Max. torque

    26.5N·m/6500 r/min

    Compression ratio

    11.5:1

    Fuel system

    EFI

    Valve train

    SOHC

    Ignition

    TCI

    Starter

    Electric

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Liquid-cooled

  • Gearbox

    6-speed

    Transmission type

    Belt

    Clutch type

    Wet multi-plate

  • Front wheel

    Alloy

    Front suspension

    Upside-down telescopic forks

    Front suspension travel (mm)

    115

    Front tyre

    Timsun 120/80-16

    Rear wheel

    Alloy

    Rear suspension

    Dual shock-absorber, 5-stage adjustable preload

    Rear suspension travel (mm)

    46

    Rear tyre

    Timsun 150/80-15

    Front brake

    Disc with ABS

    Front brakes diameter (mm)

    300

    Rear brake

    Disc with ABS

    Rear brakes diameter (mm)

    240

  • Curb weight (kg)

    175

    Seat height (mm)

    690

    Overall length (mm)

    2120

    Overall width (mm)

    836

    Overall height (mm)

    1050

    Ground clearance (mm)

    160

    Wheelbase (mm)

    1420

    Fuel capacity (L)

    15

    Top speed (km/h)

    129

    Max. load (kg)

    150

    Battery

    12V11.2Ah
