Prezzo di Listino

N/A

Potenza

2.3kW/7000/

Coppia

3.3N·m/5500 r/min

Peso a secco (kg)

116

Specifiche tecniche

  • Displacement (cc)

    49.6

    Type

    1-cylinder/4-stroke/2-valve

    Bore x Stroke (mm)

    39×41.5

    Power/rpm

    2.3kW/7000/

    Max. torque

    3.3N·m/5500 r/min

    Compression ratio

    10.4:1

    Fuel system

    EFI

    Valve train

    SOHC

    Ignition

    TCI

    Starter

    Electric & Kick

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Forced-air-cooled

  • Gearbox

    Automatic CVT

    Transmission type

    V-Belt

    Clutch type

    Automatic

  • Front wheel

    Alloy

    Front suspension

    Telescopic forks

    Front suspension travel (mm)

    75

    Front tyre

    CST 120/70-12

    Rear wheel

    Alloy

    Rear suspension

    Mono-shock-absorber

    Rear suspension travel (mm)

    46

    Rear tyre

    CST 120/70-12

    Front brake

    Disc

    Front brakes diameter (mm)

    185

    Rear brake

    Drum

    Rear brakes diameter (mm)

    130

  • Curb weight (kg)

    116

    Seat height (mm)

    790

    Overall length (mm)

    1920

    Overall width (mm)

    680

    Overall height (mm)

    1150

    Ground clearance (mm)

    130

    Wheelbase (mm)

    1360

    Fuel capacity (L)

    5

    Top speed (km/h)

    45

    Max. load (kg)

    150

    Battery

    12V7Ah
